Detailed Setup—Transducer Block
July 2013
96
Table 4‐14. Transducer Block Parameter Definitions (Continued)
Description
Protect
Category
Initial ValueRangeMode
RO /
RW
Index
Number
Label
PARAMETER_NAME
Custom Points
CUSTOM_POINTS
51 RW
MAN
OOS
Linear, Y=X SETUP
Data Type: Unit16 Array[43]
Each item - 2500 to 12500
First integrator is number of valid
points. Followed by up to 21 X
values and then 21 Y values.
X values must be increasing.
Y values must be increasing or same.
A value of 2050 represent 20.50%
Custom Points can be written only if
Input Characterization
(INPUT_CHAR [50]) is
not custom.
Travel Deviation
TRAVEL_DEVIATION
52 RO N/A 0 to 100% N/A
Data Type: Float
Absolute value of (TRAVEL_TARGET
[49] - TRAVEL [34]), Controls AI
channel 10
Drive Signal
DRIVE_SIGNAL
53 RO N/A 0 to 100% N/A
Data Type: Float
Controls AI channel 9
Drive Current
DRIVE_CURRENT
54 RO N/A 0 to 100% N/A Data Type: Float
MLFB
MLFB
55 RO N/A -100% to 100% N/A Data Type: Float
Failed Alarm
FAILED_ALM
56
Data Type: DS‐71
Used to report alerts to host system.
UNACKNOWLEDGED 56.1 RW ALL
0=Undefined
1=Acknowledged
2=Unacknowledged
0=Undefined NONE
ALARM_STATE 56.2 RO N/A
0=Undefined
1=Clear-reported
2=Clear-not reported
3=Active-reported
4=Active-not reported
0=Undefined N/A
TIME_STAMP 56.3 RO N/A 0 N/A
SUBCODE 56.4 RO N/A 0 N/A
VALUE 56.5 RO N/A 0 N/A
Data Type: Float
Value of parameter at alarm time for
single alarm, 0 for multiple alarms
Maintenance Alarm
MAINT_ALM
57
Data Type: DS‐71
Used to report alerts to host system
UNACKNOWLEDGED 57.1 RW N/A
0=Undefined
1=Acknowledged
2=Unacknowledged
0=Undefined NONE
ALARM_STATE 57.2 RO N/A
0=Undefined
1=Clear-reported
2=Clear-not reported
3=Active-reported
4=Active-not reported
0=Undefined N/A
TIME_STAMP 57.3 RO N/A 0 N/A
SUBCODE 57.4 RO N/A 0 N/A
VALUE 57.5 RO N/A 0 N/A
Data Type: Float
Value of parameter at alarm time for
single alarm, 0 for multiple alarms
-Continued-
