HyPower-Geko Technical Description
FläktGroup DC-2014-0022-GB 2018-05/R5 • Subject to modifications 13
2.3.2 External air side resistance
2.3.3 Unit and heat exchanger
User instructions!
The on-site external air-side resistance may not exceed the values 200 Pa at 300
m3/h for size 1, 500 m3/h for size 2, 700 m3/h for size 3 and 1000 m3/h for size 4.
Unit and heat exchanger Values
Max. operating pressure/temperature 1.6 MPa (16 bar) / 90 °C
Max. allowed ambient temperature 40 °C
Min. allowed ambient temperature 2 °C
Operating voltage 230 V AC, 50/60 Hz
Power consumption/protection class Refer to name plate
Max. discharge temperature 75 °C (fire hazard)
Tab. 2-2: Operating limits for unit and heat exchanger
Model size Capacity
size
Maximum medium flow rate [l/h]
2-pipe
cooling or heating
circuit
4-pipe cooling
circuit
4-pipe
heating circuit
11
2
3
700
1400
2100
1050
1400
-
342
685
-
2 1
2
3
1050
2100
3160
1580
2100
-
514
1027
-
31
2
3
1400
2800
4200
2100
2800
-
685
1370
-
4 1
2
3
1400
2800
4200
2100
2800
-
685
1370
-
Tab. 2-3: Maximum allowed medium flow rate
