Technical Description HyPower-Geko
14 FläktGroup DC-2014-0022-GB 2018-05/R5 • Subject to modifications
2.3.4 Valves with modulating actuators
2.3.5 Valves with thermoelectric actuators
2.3.6 Valves with continuous actuators
Valves with modulating
actuator 230 V/24 V
Values
230 V 24 V
Max. operating pressure/inlet temperature 1.6 MPa (16 bar) / 110 °C
Max. allowed ambient temperature 60 °C
Operating voltage 230 V AC
50/60 Hz
24 V AC
50/60 Hz
Power consumption/protection class 0.7 VA/IP43
Running time 120 s (50 Hz)
100 s (60 Hz)
150 s (50 Hz)
125 s (60 Hz)
Water Max. 50% glycol share allowable
Tab. 2-4: Operating limits for valves with modulating actuators
Valves with modulating servo drives 230 V and 2
voltage-free auxiliary switches
Values
Max. operating pressure/inlet temperature 1.6 MPa (16 bar) / 110 °C
Max. allowed ambient temperature 60 °C
Operating voltage 230 V AC, 50/60 Hz
Power consumption/protection class 0.7 VA/IP43
Running time 150 s (50 Hz); 125 s (60 Hz)
Load capacity for auxiliary switch Max. 5 (1) A/250 V
Max. 100 mA/24 V
Water Max. 50% glycol share allowable
Tab. 2-5: Operating limits for valves with modulating actuators and auxiliary switches
Valves with thermoelectric actuators
230 V/24 V
Values
M100
230 V
M100
24 V
MT4
230 V
MT4
24 V
MT8
230 V
MT8
24 V
Max. operating pressure/inlet temperature 1.6 MPa (16 bar) / 110 °C
Max. allowed ambient temperature 50 °C
Operating voltage 230 V AC
50/60 Hz
24 V AC
50/60 Hz
230 V AC
50/60 Hz
24 V AC
50/60 Hz
230 V AC
50/60 Hz
24 V AC
50/60 Hz
Power consumption/protection class 3 VA/IP43 3 VA/IP44 3 VA/IP44
Running time 180 s 280 s 150 s 240 s 210 s 360 s
water Max. 50% glycol share allowable
Tab. 2-6: Operating limits for valves with thermoelectric actuators
Valves with continuous actuators Values
Max. operating pressure/inlet temperature 1.6 MPa (16 bar) / 110 °C
Max. allowed ambient temperature 60 °C
Operating voltage 24 VAC, 50/60 Hz
Analog control signal 0 - 10 (2 - 10) V
Power consumption/protection class 1.4 VA/IP43
Running time 150 s (50 Hz); 125 s (60 Hz)
Water Max. 50% glycol share allowable
Tab. 2-7: Operating limits for valves with continuous actuators
