7.2.5 Shut-off valve for control valves from to 6.3 k
vs
(5/4") to 8.0 k
vs
(5/4") value for fan coil units
Fig. 7-5: Flow rate diagram V9440
Pre-setting 1/2 1 1 1/2 2 3 4 5 6 7
k
vs
values
0.32 0.60 1.00 1.50 2.50 3.20 3.80 4.50 5.00
Tab. 7-4: Pre-setting = turns of the pre-setting screw from the right stop position
