7.2.4 Shut-off valve for control valves from to 2.5 k
vs
(3/4") to 4.0 k
vs
(3/4") value for fan coil units
Fig. 7-4: Flow rate diagram V9441
Pre-setting 1/2 1 1 1/2 2 2 1/2 3 4 5
k
vs
values
0.20.40.611.51.722.2
Tab. 7-3: Pre-setting = turns of the pre-setting screw from the right stop position
