Appendix 2. Technical data and specications
2.1 Pressure, temperature, volume, etc.
•Systempressure(downstreamoftheunit): 1to9bar(operatingpressurerange)
•Max.permissiblesystemoverpressure: 10bar(PN10)(onthesystemconnection)
•Flowrateofmedium:   uptomax.210litres/hat1bar;upto165litres/hourat9bar
•Operatingtemperature:   3tomax.90°C(attheFlamco-FillPconnectionpoint)
•Supplysidetemperatures:   >0to105°C
•Noiseinoperation:   ~55dB(A)
•Ambienttemperatureinoperation:  >0to40°C
• Inlet water temperature: 3 to 30 °C
•Fillingwaterminimumowpressure:  1bar
•Max.llingpressure:   10bar
2.2 Weights and dimensions
Weight:  Approx.24kg(empty).
System connection: G½" screw joint on reinforced hose.
Inlet connection: External thread Rp½".
