AllFlamco-FillPcongurationsaremadeviatheSPContheexternalpressuremaintenanceunit.
5 3
2 1
6
10
11
4
15
7
13
12
8
14
9
16
1. Non-return valve
2. Water meter with pulse output
3. Float valve
4. Break tank
5. Housing cover cap
6. Overow
7. Housing
8. Pressureswitch(dryrunprotection)
9. Pump
10. System connection
11.Connection/Terminalbox
12.Feet(Optionalextras)
13. Mounting bolts for optional feet
14. Housing side panel
15. Non-return valve
16.Externalprotectiveearth(PE)conductorconnection
