FLUXUS F70x A Menu Structure
172 UMFLUXUS_F7V4-6-2EN, 2017-10-01
selection of the unit of measurement for the pressure x
selection if lb/ft
3
is to be used as the unit of measurement for the density x
selection of the unit of measurement for the density
This display will only be indicated if lb/ft
3
has not been selected as the unit of
measurement for the density
x
selection of the unit of measurement for the kinematic viscosity x
selection of the unit of measurement for the sound speed x
SYSTEM settings\Proc. inputs
selection of the displays for the setting of the inputs of the transmitter
assignment of temperature inputs and other inputs to the measuring channels
selection of the application for the heat flow measurement
heat: heating application
chill: cooling application
This display will only be indicated if the BTU mode is activated.
x
selection of the location of the flow transducers
return: the flow transducers are mounted on the return line
supply: the flow transducers are mounted on the supply line
This display will only be indicated if the BTU mode is activated.
x
selection if the sign of the measured values of the heat flow is to be considered
sign: the sign of the heat flow is to be considered
absolute: only the absolute value of the heat flow is to be displayed
This display will only be indicated if the BTU mode is activated.
x
selection of the temperature input to be assigned to the supply temperature
This display will only be indicated if the BTU mode is activated.
x
selection of the temperature input to be assigned to the return temperature.
This display will only be indicated if the BTU mode is activated.
x
SYSTEM settings\Measuring
selection of the displays for the settings of the measurement
activation of the WaveInjector (optional) x
INIT-
resistant
Pressure
>[bar]< [psi]
Density [lb/ft3]
no >YES<
Density unit
g/cm3 >kg/m3<
Viscosity unit
mm2/s >cSt<
Soundspeed unit
>[m/s]< [fps]
SYSTEM settings↕
Proc. inputs
Proc. inputs ↕
Link temperature
A:Thermal energy
>HEAT< chill
Transd. Location
>RETURN< supply
Thermal energy
>ABSOLUTE< sign
A:T-Supply ↕
Input T1
A:T-Return ↕
Input T2
SYSTEM settings↕
Measuring
WaveInjector
off >ON<
