9.2 Parameter input
The pipe and fluid parameters are entered for the selected
measuring point. The parameter ranges are limited by the
technical characteristics of the transducers and the
transmitter.
• Select the program branch Parameters.
• Press ENTER.
• Select the channel for which the parameters are to be
entered (here: Channel A).
• Press ENTER.
The display will not be indicated if the transmitter has only
one measuring channel.
9.2.1 Transducer selection
• The transducer (here: CDP2E52) connected to the transmitter is displayed.
• Press ENTER.
The display will only be indicated if a SENSPROM is connected to the transmitter.
Notice!
Avoid a simultaneous parameter entry via the keyboard and the USB, LAN or process interface. The parameter
records received via these interfaces will overwrite the current transmitter parameterization.
Parameters
Channel x
Transducer
Connected transd. Select transducer
Outer diameter
Pipe material
Pipe wall thickness
Lining
Roughness
Fluid
Fluid temp.
Fluid pressure
Select analysis quant.
Definition of the operating point
Extension cable
see annex A
Parameters\Channel A
Notice!
The transducers have to be selected depending on the application parameters (see technical specification).
Parameters\Clamp-on transducer CDP2E52
