17 Data logger
17.1 Configuration of the data logger FLUXUS H721
2022-05-15, UMFLUXUS_H721V1-5EN
166
17 Data logger
The transmitter has a data logger which stores the
measured values during the measurement.
The following data can be stored:
•date
•time
• measuring point number
• pipe parameters
• fluid parameters
• transducer data
• physical quantity
• unit of measurement
• measured values
• sound speed
• change of the fluid properties
• current fluid
Measured values transmitted via the outputs are also
stored in the data logger.
If the pulse values are transmitted via an output, the
corresponding flow quantity and the totalizer value are
stored in the data logger. In case of absolute pulse values,
the values of both totalizers are stored.
17.1 Configuration of the data logger
Activation of the channels for storing
• Select the menu item Configuration.
• Press ENTER.
• Activate the channels whose measured values have to be stored.
• Press or to select a channel.
• Press to activate/deactivate a channel.
• Press ENTER.
Starting time
It is possible to set a starting time if it is necessary to synchronize the storing of measured values for several transmitters.
• Select the menu item Configuration.
• Press ENTER until the menu item Start storing is displayed.
• Select the moment at which to start the storing.
Special functions
Data logger
Configuration
Logger channels
Start storing
Storage rate FastF
Ringbuffer
On Off
Storage mode
Average Sample
Store totalizers
Store diagnost.
values
Store transd. temp.
see annex A
In order to store measured data, the data logger has
to be configured.
Special functions\Data logger\Configuration\Logger channels
Special functions\
Data logger\
Configuration\Start storing
