9 Measurement
FLUXUS H721 9.1 Enabling the HPI measuring mode
103
UMFLUXUS_H721V1-5EN, 2022-05-15
The range of the source item for each fluid has to be entered. The ranges must not overlap.
• Enter the min. value of the selected source item.
• Press ENTER.
• Enter the max. value of the selected source item.
• Press ENTER.
From the SuperUser mode, the following menu items are displayed additionally:
Deviating from the global device settings in the menu item CTL method, a separate CTL calculation can be selected for
the respective fluid.
•Select Yes if a separate CTL calculation has to be selected for the fluid.
• Press ENTER.
• Select the CTL calculation to be used.
• Press ENTER.
• Select a list item to be used as a basis for the calculation.
• Press ENTER.
Deviating from the global device settings in the menu item CPL method, a separate CPL calculation can be selected for
the respective fluid.
•Select Yes if a separate CPL calculation has to be selected for the fluid.
• Press ENTER.
• Select the CPL calculation to be used.
• Press ENTER.
If the fluid-specific calibration factor for a detected fluid from the fluid table is known, it can be entered.
•Select Yes to enter a fluid-specific calibration factor.
• Press ENTER.
• Enter the calibration factor.
• Press ENTER.
Special functions\Measurement\Measurement modes\...\min.
Special functions\Measurement\Measurement modes\...\max.
Special functions\Measurement\Measurement modes\...\Spec. CTL method
Special functions\Measurement\Measurement modes\...\Spec. CPL method
Special functions\Measurement\Measurement modes\...\Flow calib. factor
