PIOX S70x 2 Handling
10 UMPIOX_S7V4-6-3EN, 2018-10-10
2 Handling
2.1 First Inspection
The measuring instrument has already been tested thoroughly at the factory. At delivery, proceed to a visual control to
make sure that no damage has occurred during transportation.
Check that the specifications of the measuring instrument delivered correspond to the specifications given on the pur-
chase order.
The type and the serial number of the transmitter are shown on the nameplate. The transducer type is printed on the trans-
ducers.
2.2 General Precautions
PIOX S is a precision measuring instrument and has to be handled with care. To obtain good measurement results and
not damage the measuring instrument, it is important that great attention is paid to the instructions given in this user man-
ual, particularly to the following points:
• Protect the transmitter from shocks.
• The housing may only be opened by authorized personnel. The degree of protection of the transmitter PIOX S704, S705
will only be ensured if the front plate is tightly screwed to the housing.
• Keep the transducers clean. Manipulate the transducer cables with caution. Avoid excessive cable bend.
• Make sure to work under correct ambient and operating temperatures. The ambient temperature has to be within the op-
erating temperature range of the transmitter and the transducers (see Technical Specifications).
• Observe the degree of protection (see Technical Specifications).
2.3 Cleaning
• Clean the transmitter with a soft cloth. Do not use detergents.
• Remove traces of the coupling compound from the transducers with a soft paper towel.
Attention! Observe the Safety Instructions for the Use in Explosive Atmosphere (see document SIFLUXUS).
