4 Description of the Transmitter PIOX S70x
UMPIOX_S7V4-6-3EN, 2018-10-10 19
4.4 Keyboard
The keyboard consists of three function keys ENTER, BRK and C and ten numerical keys.
Several keys have double functions. They can be used for entering data and for navigating through scroll lists.
The arrow-shaped keys , , and are used as cursor keys in the selection mode and for entering digits and
letters in the input mode.
Tab. 4.1: General functions
ENTER confirmation of selection or of entered value
BRK + C + ENTER RESET: Press these three keys simultaneously to correct a malfunction. The reset has the same
effect as restarting the transmitter. Stored data are not affected.
BRK interruption of the measurement and selection of the main menu
Be careful not to stop a current measurement by inadvertently pressing key BRK!
Tab. 4.2: Navigation
BRK selection of the main menu
scroll to the left/right through a scroll list
scroll upwards/downwards through a scroll list
ENTER confirmation of the selected menu item
Tab. 4.3: Input of digits
... input of the digit shown on the key
sign for the input of negative values
decimal marker
C Delete values. After the value has been deleted, the previous value will be displayed.
ENTER confirmation of input
Tab. 4.4: Input of text
positioning of the cursor
changing the currently selected character to an "A"
changing the currently selected character to a "Z"
changing between small and capital letters
selection of the previous/next ASCII character
deleting the character and inserting a blank
... Automatic scrolling up or down through the limited ASCII character set. The character changes ev-
ery second. The scrolling is stopped by pressing any other key.
ENTER finishing editing
