• Connect the RS485 cable to the terminals of the transmitter (see Fig. 7.3, Fig. 7.47 and Tab. 7.19).
For further information on the data transmission see chapter 13.
7.7 Sensor Module (SENSPROM)
The sensor module contains important transducer data for the operation of the transmitter with the transducers.
With the transducers of the connection system AS, the sensor module is integrated in the transducer. They are connected
via AMP-Quick connectors (see Fig. 7.48).
With the transducers of the connection system TS, the sensor module is supplied separately. The sensor module is al-
ready connected to the terminals of the transmitter (see Fig. 7.49).
Fig. 7.47: Transmitter PIOX S709
Attention! Observe the "Safety Instructions for the Use in Explosive Atmosphere" (see document SIFLUXUS).
Fig. 7.48: Transmitter PIOX S704
(connection system AS)
Fig. 7.49: Transmitter PIOX S704
(connection system TS)
Attention! The AMP-Quick connector and the separate sensor module must never be connected to the trans-
mitter at the same time.
