PIOX S70x 6 Installation
28 UMPIOX_S7V4-6-3EN, 2018-10-10
6.3 Transmitter PIOX S709
The transmitter is designed as a 19 " module (42 HP, 3 U).
Fig. 6.4: Installation of the transmitter
PIOX S704
Fig. 6.5: Installation of the transmitter
PIOX S705
Fig. 6.6: Pipe installation using tension straps
Fig. 6.7: Front and back view
5
2
3
2
3
