19 Outputs PIOX S70x
UMPIOX_S7V4-6-3EN, 2018-10-10 157
19 Outputs
If the transmitter is equipped with outputs, they have to be installed and activated before they can be used:
assign a measuring channel (source channel) to the output (if the transmitter has more than one measuring channel)
assign the physical quantity (source item) to be transmitted to the output by the source channel, and the properties of the
signal
define the behavior of the output in case no valid measured values are available
activation of the installed output in the program branch Output Options
19.1 Installation of an Output
All outputs are installed in Special Funct.\SYSTEM settings\Proc. outputs.
The source items and their scroll lists are shown in Tab. 19.1.
Note! The configuration of an output will be stored at the end of the dialog. If the dialog is quit by pressing
key BRK, the changes will not be stored.
Select Special Funct.\SYSTEM settings\Proc. outputs. Press ENTER.
Select the output to be installed. Press ENTER.
The scroll list contains all available outputs. A tick after a list item indicates that this out-
put has already been installed.
Select active if all current outputs to be installed are to be operated as active current out-
puts.
Select passive if all current outputs to be installed are to be operated as passive current
outputs.
This display will only be indicated if the transmitter is equipped with switchable current out-
puts.
This display will be indicated if the output has not been installed yet. Select yes. Press EN-
TER.
If the output has already been installed, select no to reconfigure it or yes to uninstall the
output and to return to the previous menu item to select another output. Press ENTER.
Select in the scroll list the measuring channel to be assigned to the output as the source
channel. Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
Select the physical quantity (source item) to be transmitted from the source channel to the
output.
If a binary output is configured, only the list items Limit and Impuls will be displayed.
SYSTEM settings
Proc. outputs
Install Output
Current I1 ()
Loop I1,I2
passive >ACTIVE<
I1 enable
no >YES<
I1 disable
>NO< yes
I1 Source chan.
Channel A:
I1 Source item
Measuring value
