PIOX S70x 13 Data Logger and Transmission of Data
122 UMPIOX_S7V4-6-3EN, 2018-10-10
Max. 100 series of measured values can be stored. The number of series of measured values depends on the total num-
ber of measured values stored in the previous series of measured values.
The time at which the data logger memory will be full can be displayed during the measurement. All activated channels, to-
talizers and other values will be considered.
13.2 Transmission of Data
The measurement data can be transmitted to a PC via the serial interface RS232 or RS485 (optional) or stored on an SD
card (optional).
13.2.1 Online Transmission of Data
The measurement data are transmitted during the measurement.
It is possible to:
• transmit the measurement data to a terminal program
• store the measurement data on an SD card
The data logger works independently of the online transmission of data.
13.2.2 Offline Transmission of Data
The measurement data of the data logger are transmitted.
Selection of the serial interface for the offline transmission of data
Select Special Funct.\SYSTEM settings\serial transmis.. Press ENTER until Send Offline via is dis-
played.
Press key during the measurement to scroll through the displays of the upper line.
If the ringbuffer is activated and has overflown at least once, this display will be indicated.
Tab. 13.1: Overview online transmission of data
serial interface transmission of data see
RS232 terminal program section 13.2.5
RS485 (sender) terminal program / SD card section 13.2.5
Note! It is recommended to use the RS485 interface for the online transmission of data. The RS232 inter-
face should only be used if the transmitter does not have an RS485 interface.
Tab. 13.2: Overview offline transmission of data
serial interface transmission of data see
RS232 terminal program section 13.2.6
RS232 FluxData section 13.2.7
RS485 (sender) terminal program section 13.2.6
Select the serial interface for the offline transmission of data.
This display will only be indicated if the transmitter has an RS485 interface.
full= 26.01/07:39
54.5 m3/h
last= 26.01/07:39
54.5 m3/h
Send Offline via
RS232 >RS485<
