FlexRadio Systems Flex-3000 User Manual

O P E R A T I O N C H A P T E R 6
Initial Settings
1. Follow the Power Up Procedure, described on page 132. Then click the Start button (14). Set
the following controls as specified in Table 10.
Table 10: Initial Control Values for CW Transmission
Ctrl Value
Reference to
Figure 141
VFO A 14.05MHz (1)
RX Meter Signal (4)
TX Meter Fwd Pwr (4)
Band 20m (5)
Mode CWU (6)
Filter 500Hz (7)
VAC Off (8)
Display Mode Panadapter (9)
AVG On (9)
PEAK Off (9)
MultiRX Off (10)
SPLT Off (12)
XIT Off (12)
RIT Off (12)
MON On (15)
MUT Off (17)
AF 50 (21)
AGC-T 70 (22)
Drive 25 (23)
AGC Med (24)
RX Gain Pre (25)
SQL Off (26)
2. Connect a 50 ohm dummy load to the antenna jack, or tune VFO A (1) to a quiet frequency on
the selected band. Use the TUN (19) button to verify power output on the TX Meter (4) (Set
to Fwd Pwr). If using the integrated ATU click the ATU (20) button to initiate a tuning cycle.
CAUTION: If you are not using the internal ATU then connect a 50 ohm dummy
load, or ensure that the antenna presents a 50 ohm load with a low
SWR. Failing to do so may damage the FLEX-3000 output transistors.
[The rest of this page has been left blank intentionally]
139  2003-2009 FlexRadio Systems
