FLI R Duo User Guide
436-0100-01-10, Rev. 200 Duo User Guide
Information on this page is subject to change without notice
60
Struct {
Ureal8_t u8R esolution ; // output resolution, see HDMI_RESOLUTION definition
Byte Reserve [3]; // Reserved
};
HDMI_RESOLUTION Definition:
Typedef enum {
HDMI_RESOLUTION_720P30 = 0,
HDMI_RESOLUTION_720P60 = 1,
HDMI_RESOLUTION_1080 P30 = 2,
HDMI_RESOLUTION_1080P60 = 3,
} HDMI_RESOLUTION;
CRC Description :
In CSP-TCP applications, the CRC is ignored
Response command:
Instruction Application: UART /
TCP
Data flow: CS ---  G / A
Identification
code
1 Byte
status code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
CRC1
/ reserved
2 Bytes
0x64
Status Code
0x100F
0x00
CRC
Instruction body
0 Bytes
CRC2
/ reserved
2 Byte s
air
CRC
Description:
In CSP-TCP applications, the CRC is ignored
3.8 MSX edge enhancement
3.8.1 query
Request instruction
Instruction Application: UART /
TCP
Data flow: G / A ---  CS
Identification
code
status code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
CRC1
/ reserved
