436-0100-01-10, Rev. 200 Duo User Guide
Information on this page is subject to change without notice
CRC Description:
In CSP-TCP applications, the CRC is ignored
Instruction Application: UART /
TCP
Data flow: CS --- G / A
Identification
code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
Instruction body format:
Struct {
BOOL bEnable ; // the MSX enabled, 1- open, 0- off
UX8S trength ; // MSX strength, 0 ~ 100
Int8_t s8PosX; // MSX X coordinates , -100 ~ 100
Int8_t s8PosY; // MSX X coordinates , -8 ~ 8
};
CRC Description :
In CSP-TCP applications, the CRC is ignored
3.8.2 settings
Request instruction
Instruction Application: UART /
TCP
Data flow: G / A --- CS
Instruction number
2 Bytes
Instruction length
2 Bytes
