FLI R Duo User Guide
436-0100-01-10, Rev. 200 Duo User Guide
Information on this page is subject to change without notice
62
1 Byte
2 Bytes
0x64
0x0 0
0x1012
0x04
CRC
Instruction body
4 Bytes
CRC2
/ reserved
2 Bytes
Instruction body format:
Struct {
BOOL bEnable ; // the MSX enabled, 1- open, 0- off
UX8S trength ; // MSX strength, 0 ~ 100
Int8_t s8PosX; // MSX X coordinates , -100 ~ 100
Int8_t s8PosY; // MSX X coordinates , -8 ~ 8
};
CRC
CRC Description :
In CSP-TCP applications, the CRC is ignored
Response command:
Instruction Application: UART /
TCP
Data flow: CS ---  G / A
Identification
code
1 Byte
status code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
CRC1
/ reserved
2 Bytes
0x64
Status Code
0x1013
0x00
CRC
Instruction body
0 Bytes
CRC2
/ reserved
2 Bytes
air
CRC
Description:
In CSP-TCP applications, the CRC is ignored
3.9 SD card
3.9.1 Status information
Information query for the specified SD card, including capacity, status.
Request instruction
Instruction Application: UART /
TCP
Data flow: G / A ---  CS
