Identification
code
1 Byte
status code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
CRC1
/ reserved
2 Bytes
0x64
0x00
0x1014
0x04
CRC
Instruction body
4 Bytes
CRC2
/ reserved
2 Bytes
Instruction body format:
Struct {
uint8_t u8SDcardNo; // SD card number, from 1 to start
Byte Reserve [3]; // Reserved
};
CRC
CRC Description :
In CSP-TCP applications, the CRC is ignored
Response command:
Instruction Application: UART /
TCP
Data flow: CS ---  G / A
Identification
code
1 Byte
status code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
CRC1
/ reserved
2 Bytes
0x64
Status Code
0x1015
0x0C
CRC
Instruction body
12 Bytes
CRC2
/ reserved
2 Bytes
Instruction body format:
Struct {
uint8_t u8SDcardNo; // SD card number, from 1 to start
// SD card status, 0 - available 1 nonexistent 2 - card full 3 - exception 4 - format
error or format unrecognizable
Byte Reserve [2]; // Reserved
Uint32_t u32 Total ; // total capacity in megabytes
Uint32_t u32Free; // remaining capacity in megabytes
};
CRC
Description:
