Instruction Application: UART /
TCP
Data flow: G / A ---  CS
Identification
code
1 Byte
status code
1 Byte
Instruction number
2 By tes
Instruction length
2 Bytes
CRC1
/ reserved
2 Bytes
0x64
0x00
0x1020
0x04
CRC
Instruction body
4 Bytes
CRC2
/ reserved
2 Bytes
Instruction body format:
Struct {
BOOL bEnable; 0- // Close 1- opening
Byte Reserve [3]; // Reserved
};
CRC
CRC Description :
In CSP-TCP applications, the CRC is ignored
Response command:
Instruction Application: UART /
TCP
Data flow: CS ---  G / A
Identification
code
1 Byte
status code
1 Byte
Instruction number
2 Bytes
Instruction length
2 Bytes
CRC1
/ reserved
2 Bytes
0x64
Status Code
0x1021
0x00
CRC
Instruction body
0 Bytes
CRC2
/ reserved
2 Bytes
air
CRC
CRC Description :
In CSP-TCP applications, the CRC is ignored
3.12 PIP position
3.12.1 query
Request instruction
