M-Series System Configuration
36 432-0003-00-10 Rev 150 — M-Series Operator’s Manual
Note: The PC and JCU icons do not display in minimal mode even when their
icon settings are enabled.
Hide All Icons
None of the icons display permanently, except for the FLIR logo, the azimuth
(pan position) icon, and icons for the following special modes:
• Rearview mode enabled
• Freeze video
• Stabilization disabled
• Point enabled
Transitory icons display when selected functions are used, such as pressing the
HOME button.
User Programmable Button
When you select User Programmable Button from the main menu, the following
on-screen menu displays. (An additional option is available when you are using a
camera with stabilization; see page 48.)
Note: It is also possible to enter this menu by pressing and holding the USER
button for 3 seconds.
The USER button is a programmable one-touch button that lets you quickly
access the most common or favorite settings or functions. You use this menu to
select a function to associate with the USER button by selecting one of the six
choices; Invert Video Polarity is the default selection. The active choice is shown
in black type.
Man-Over-Board settings. A short press of the USER button causes the
thermal camera to use the Man Overboard AGC setting. This is one of the
settings available from the SCENE button (see page 17).
Man-Over-Board settings
Switch IR/VIS Video
Hide/Show All Icons
Invert Video Polarity
Rearview Mode (Revert)
Surveillance Mode
Exit
<Press Puck to Select>
