M-Series IP Interface and PC Operations
58 432-0003-00-10 Rev 150 — M-Series Operator’s Manual
appear here with a generic icon based on the device type. In the future when a
UPnP device is installed on the network, a notifying icon will appear briefly in the
System Tray. When you see this icon, go to My Network Places to view the new
device. Double-click on the icon to bring up the Web page.
Network Settings
By default, the camera and JCU device are configured to automatically
determine IP addresses dynamically through UPnP. It is also possible to
configure static IP addresses to coincide with addresses on an existing network.
Changing the IP Address of the Camera
You cannot display the camera’s IP address on the JCU display. Instead, you do
it from the control page. Clicking the Network Settings link displays the camera IP
address, mask, and gateway, as show in the figure below. The Dynamic option is
selected by default.
To enter a static IP address, select the Static option rather than Dynamic. The
screen will refresh, and the IP, mask, and gateway fields will change from gray to
white, indicating they can accept user entries. Enter the appropriate information,
then click the Save link.
