432-0003-00-10 Rev 150 — M-Series Operator’s Manual 67
M-Series Reference Information
System Specifications
Table 6.3 lists details about physical characteristics, power usage, and
environmental features of your M-Series camera.
TABLE 6.3 Specifications
Physical Characteristics
Camera Size 17.8 cm (7 in) diameter by under 29.2 cm (11.5 in) tall
Camera Weight Under 5.4 kg (12 lb), depending on the camera model
Joystick Size 9.1 X 14.2 X 8.13 cm (3.6 X 5.6 X 3.2 in)
3.17 cm (1.25 in) above platform including joystick
Joystick Weight .45 kg (1 lb)
Power
Camera Input Power 12 – 24 V DC nominal, 5 A Max
Absolute range 10 – 32V DC
(–10%/+30% per IEC 60945)
Camera Output Power (to
JCU)
Power Over Ethernet (PoE) per IEEE 802.3af
48V mode B PoE, RJ45
JCU Input Power Power over Ethernet (PoE) per IEEE 802.3af
Consumption 25W Nominal
42W Max (dual payload)
Environmental
Operating temperature
range
–25° C to +55° C (–11° F to +131° F)
Storage temperature range –40º C to +85º C (–38º F to +185º F)
Automatic Window defrost Standard (automatic at unit power-up)
Sand/dust Mil-Std-810E
Automatic Window de-icing Standard (automatic at unit power-up)
Water Ingress IPX 6
Shock 15 g vertical, 9 g horizontal
Vibration IEC 60945; MIL-STD-810E
Lightening Protection Standard
Salt Mist IEC 60945
Wind 100 knot (115.2 mph)
EMI IEC 60945
