FLIR M300 Series User Manual

12.2FLIRnetworkingaccessories
1
Power-over-Ethernet(PoE)networkswitch.4-portIEEE802.3at-compliantPoEfunction
with30Wpoweroutputperport.
2
RJ45coupler,forjoining2separateRJ45networkcablestogethertoachievelonger
cableruns.
3
Power-over-Ethernet(PoE)injector.Suppliespowertoanon-PoEneworkconnection.
T ypicaluseisforpoweringaJCUcontrollerthatisconnectedtoanon-PoEnetwork
switch.
4
305mm(1ft.)RJ45–to-RJ45Ethernetcable,doubleshieldedwithLSZHlow
interferencejacket.
5
7.6m(25ft.)RJ45–to-RJ45Ethernetcable,doubleshieldedwithLSZHlow
interferencejacket.
6
15.2m(50ft.)RJ45–to-RJ45Ethernetcable,doubleshieldedwithLSZHlow
interferencejacket.
7
22.8m(75ft.)RJ45–to-RJ45Ethernetcable,doubleshieldedwithLSZHlow
interferencejacket.
8
30.4m(100ft.)RJ45–to-RJ45Ethernetcable,doubleshieldedwithLSZHlow
interferencejacket.
Sparesandaccessories
103

FLIR M300 Series Specifications

General

Thermal Sensor	Uncooled VOx Microbolometer
Pan/Tilt	360° continuous pan, +/- 90° tilt
IP Rating	IP66
Frame Rate	30 Hz
Input Voltage	12-24 VDC
Spectral Range	7.5 - 13.5 µm
Operating Temperature	-25°C to +55°C
Thermal Sensitivity	<50 mK
Focus	Automatic
Resolution	640 × 512 (M364), 320 × 256 (M332)
