Suppressionferrites
•Cablesmaybepre-ttedorsuppliedwithsuppressionferrites.Theseareimportantfor
correctEMCperformance.Ifferritesaresuppliedseparatelytothecables(i.e.not
pre-tted),youmusttthesuppliedferrites,usingthesuppliedinstructions.
•Ifaferritehastoberemovedforanypurpose(e.g.installationormaintenance),itmustbe
replacedintheoriginalpositionbeforetheproductisused.
•Useonlyferritesofthecorrecttype,suppliedbythemanufactureroritsauthorizeddealers.
•Whereaninstallationrequiresmultipleferritestobeaddedtoacable,additionalcableclips
shouldbeusedtopreventstressontheconnectorsduetotheextraweightofthecable.
•Ifyourcamerainstallationrequireslongcableruns,youmayneedtotadditionalferrites
tomaintainacceptableEMCperformance.
Connectionstootherequipment
Requirementforferritesonnon-FLIRcables
IfyourFLIRequipmentistobeconnectedtootherequipmentusingacablenotsuppliedby
FLIR,asuppressionferriteMUSTalwaysbeattachedtothecableneartheFLIRunit.
DeclarationofConformity
FLIRBelgiumBVBAdeclaresthatthefollowingproductsareincompliancewiththeEMC
Directive2014/30/EU:
•M364C30Hzdualpayloadthermalcamera,partnumberE70518
•M364C9Hzdualpayloadthermalcamera,partnumberE70519
•M364C30Hzdualpayloadthermalcamera,partnumberE70520
•M364C9Hzdualpayloadthermalcamera,partnumberE70521
•M36430Hzsinglepayloadthermalcamera,partnumberE70525
•M3649Hzsinglepayloadthermalcamera,partnumberE70526
•M33230Hzsinglepayloadthermalcamera,partnumberE70527
•M3329Hzsinglepayloadthermalcamera,partnumberE70528
•M300C30Hzsinglepayloadcamera,partnumberE70605
TheoriginalDeclarationofConformitycerticatemaybeviewedontherelevantproduct
pageatwww.ir.com/marine.
Productdisposal
DisposeofthisproductinaccordancewiththeWEEEDirective.
TheWasteElectricalandElectronicEquipment(WEEE)Directiverequirestherecycling
ofwasteelectricalandelectronicequipmentwhichcontainsmaterials,componentsand
substancesthatmaybehazardousandpresentarisktohumanhealthandtheenvironment
whenWEEEisnothandledcorrectly.
Equipmentmarkedwiththecrossed-outwheeledbinsymbolindicatesthat
theequipmentshouldnotbedisposedofinunsortedhouseholdwaste.
Localauthoritiesinmanyregionshaveestablishedcollectionschemes
underwhichresidentscandisposeofwasteelectricalandelectronic
equipmentatarecyclingcenterorothercollectionpoint.
Formoreinformationaboutsuitablecollectionpointsforwasteelectrical
andelectronicequipmentinyourregion,refertotheRaymarinewebsite:
www.raymarine.eu/recycling.
12

FLIR M300 Series Specifications

General

Thermal Sensor	Uncooled VOx Microbolometer
Pan/Tilt	360° continuous pan, +/- 90° tilt
IP Rating	IP66
Frame Rate	30 Hz
Input Voltage	12-24 VDC
Spectral Range	7.5 - 13.5 µm
Operating Temperature	-25°C to +55°C
Thermal Sensitivity	<50 mK
Focus	Automatic
Resolution	640 × 512 (M364), 320 × 256 (M332)
