FLIR M300 Series User Manual

5.3Cameracontrol
Pan,tiltandzoom
Thecameracontrolsallowforpan(azimuth)andtilt(elevation)ofthecamera,aswellas
zoom(magnication)ofthethermalimage.
•Pancontinuouslythrough360°.
•Tiltto+110°/-90°relativetothecamerabase.
•Zoomthethermalcameraimage.
Y oucancontrolpan,tilt,andzoom,using:
•thecamera’swebbrowserinterface:seep.75—Webinterfaceoperation
•theJoystickonaJCUremotekeypad:seep.82—JCU–2controlsoverview
•thetouchscreenofacompatibleRaymarineMFD:seethe“Videoapp”sectioninthe
documentationsuppliedwithyourMFD.
Homeposition
Thehomepositionisapresetpositionforthecamera.
Thehomepositionusuallydenesausefulreferencepoint—forexample,straightahead
andlevelwiththehorizon.
•Thehomeiconisdisplayedmomentarilywhenyoucommandthe
cameratomovetoitshomeposition.
•Thehomeiconashes3timeswhenyousetthecamera’shome
position.
Cameracontroloptionsandstatusicons
73

FLIR M300 Series Specifications

General

Thermal Sensor	Uncooled VOx Microbolometer
Pan/Tilt	360° continuous pan, +/- 90° tilt
IP Rating	IP66
Frame Rate	30 Hz
Input Voltage	12-24 VDC
Spectral Range	7.5 - 13.5 µm
Operating Temperature	-25°C to +55°C
Thermal Sensitivity	<50 mK
Focus	Automatic
Resolution	640 × 512 (M364), 320 × 256 (M332)
