FLIR M300 Series User Manual

5.Placetherubberbasesealonthebottomoftheriser.
6.Slideaatwasher,andthenaspringwasher,ontoeachstud.
7.Securethecamerabodytotheriserwiththesuppliednuts,ensuringthatthesealremains
correctlypositionedonthecamera’sbase.
Tightenthenutstoatorqueof3.7N·m(2.7lbf·ft).
8.Connectthepowersupplycable,BNCcableandnetworkcabletothecamera,thenloop
thecablesroundwithintheriserbasesothattheycanbethreadedthroughthebottomof
theriser,andintothecableroutingholedrilledinthemountingsurface.
9.Ensuretheriser-basesealispositionedcorrectly,andthenfastenthecamera-riser
assemblytothemountingsurfaceusingfastenersappropriateforthesurface’sthickness
andmaterial.Donotusethreadlockingcompound,asthismaydamagetheplasticriser.
Y oumustensureawatertightsealbetweentheriserbaseandthemountingsurface.Y ou
mayuseamarine-gradesealantasanalternativetothesuppliedmountinggasket.
Note:
•Ifitisnotpossibletoroutethecameracablesthroughthemountingsurface,cutahole
inthesideoftheriser,androutethecablesthroughtherisersidewall.Youmayneedto
loopthecablesaroundwithintheriserbase,sothattheycanbepassedthroughthe
holeyouhavecutinthesideoftheriser.
•Ifroutingthecameracablesthroughtherisersidewall,andthecameraismounted
ball-up,doNOTsealtheriserbasewitheitherthesuppliedgasket,orsealant.Sealing
mayresultinwaterpoolinginsidetheriser.
•Ifroutingthecameracablesthroughtherisersidewall,andthecameraismounted
ball-down,doNOTsealtheconnectionbetweenthecamerabaseandthetopsurfaceof
theriserwiththesuppliedgasket.Sealingmayresultinwaterpoolinginsidetheriser.
36

FLIR M300 Series Specifications

General

Thermal Sensor	Uncooled VOx Microbolometer
Pan/Tilt	360° continuous pan, +/- 90° tilt
IP Rating	IP66
Frame Rate	30 Hz
Input Voltage	12-24 VDC
Spectral Range	7.5 - 13.5 µm
Operating Temperature	-25°C to +55°C
Thermal Sensitivity	<50 mK
Focus	Automatic
Resolution	640 × 512 (M364), 320 × 256 (M332)
