aPoweroverEthernet(PoE)Injector(availableseparately),andawebbrowser(laptop)
(availableseparately)foradditionalcameracontrol.
Single-camerasystemwithRaymarineMFDandJCU
Note:Powerconnectionsarenotshowninthisillustration.Thecameraandtheother
devicesshownrequiretheirowndedicatedpowerconnection.
1
M300Seriescamera
2
Joystickcontrolunit(JCU-2),availableseparately
3
RaymarineMFD,availableseparately
4
RayNetnetworkswitch,availableseparately
5
Right-angledRayNet-to-RayNetcable,(suppliedwithcamera)
6
RJ45–to-RJ45cable,availableseparately
7
PoEinjector(providespowertoJCU-2),availableseparately
8
RayNet-to-RJ45adaptercable,(120mm/4.7in.versionsuppliedwith
camera;otherlengthsavailableseparately)
Connections57
