FLIR T530 User Manual

Technical data27
Image presentation
Screen size 4 in.
Viewing angle 80°
Color depth (bits)
24
Aspect ratio 4:3
Auto-rotation Yes
Touchscreen Optically bonded PCAP
Display technology IPS
Cover glass material Dragontrail®
Programmable buttons 2
Viewfinder No
Image adjustment
• Automatic
• Automatic maximum
• Automatic minimum
• Manual
Image presentation modes
Infrared image Yes
Visual image Yes
MSX Yes
Picture in picture Resizable and movable
Gallery
Yes
Measurement
Object temperature range
• –20 to +120°C (–4 to +248°F)
• 0–650°C (32–1202°F)
• Optional: 300–1200°C (572–2200°F)
Accuracy
±2°C (±3.6°F) or ±2% of reading, for ambient tem-
perature 15–35°C (59–95°F) and object tempera-
ture above 0°C (32°F)
Measurement analysis
Spotmeter 3 in live mode
Area 3 in live mode
Automatic hot/cold detection Automatic maximum/minimum markers within area
Color alarm (Isotherm)
• Above
• Below
• Interval
• Condensation
• Insulation
Measurement presets
• No measurements
• Center spot
• Hot spot
• Cold spot
• User preset 1
• User preset 2
Difference temperature Yes
Reference temperature Yes
#T810253; r. AA/42549/42549; en-US
107

FLIR T530 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	< 30 mK
Digital Zoom	1-4x continuous
Image Modes	Thermal, MSX, Picture-in-Picture
Storage	SD card
Image Frequency	30 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	5 MP
Laser Distance Meter	Yes
Wi-Fi	Yes
Video Recording	Yes
Video Output	HDMI
Minimum Focus Distance	0.15 m (0.49 ft)
Operating Temperature Range	-15°C to 50°C (5°F to 122°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
Temperature Range	0°C to +650°C
Field of View	24° × 18°
Display	4-inch LCD touchscreen
Battery Life	Approx. 4 hours
Focus	Continuous, one-shot contrast, manual
Spectral Range	7.5-14 µm
Weight	1.3 kg (2.9 lbs)
Connectivity	Wi-Fi, USB
Lens Options	14°, 24°, 42°
