FLIR T530 User Manual

Handling the camera11
• Save + Prompt for voice annotation: Save an image and display the voice annotation
tool.
• Save + Prompt for sketch: Save an image and display the sketch annotation tool.
• Save + Select annotation from menu: Save an image and display the annotation tool
menu.
• Preview: Display a preview image.
• Preview + Prompt for note: Display a preview image and the note annotation tool.
• Preview + Prompt for table: Display a preview image and the table annotation tool.
• Preview + Prompt for voice annotation: Display a preview image and the voice annota-
tion tool.
• Preview + Prompt for sketch: Display a preview image and the sketch annotation tool.
• Preview + Select annotation from menu: Display a preview image and the annotation
tool menu.
11.12.2 Procedure
Follow this procedure:
1. Push and hold the programmable button
. This displays the Programmable button
menu.
2. Push the navigation pad up/down to select one of the functions. Push the center of the
navigation pad to confirm.
11.13 Using the camera lamp as a flash
11.13.1 General
The camera lamp can be used as a flash for the digital camera. When the flash function is
enabled, the camera lamp will flash when an image is saved by pushing the Save button.
You can also turn on the camera lamp to use it as a flashlight.
11.13.2 Procedure
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Select
(Settings) and push the navigation pad. This displays the Settings menu.
3. Use the navigation pad to select Device settings > Lamp & laser.
4. Do one of the following:
• To enable the camera lamp function, select Enable lamp & laser and push the navi-
gation pad. To turn on/off the camera lamp, touch the soft button
.
• To enable the flash function, select Enable lamp & laser + Use lamp as flash and
push the navigation pad.
• To disable the camera lamp and flash functions, select Disable all and push the nav-
igation pad.
Note You can also assign the function Switch camera flash On <> Off to one of the pro-
grammable buttons
. For more information, see section 11.12 Assigning functions to
the programmable buttons, page 37.
#T810253; r. AA/42549/42549; en-US
39

FLIR T530 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	< 30 mK
Digital Zoom	1-4x continuous
Image Modes	Thermal, MSX, Picture-in-Picture
Storage	SD card
Image Frequency	30 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	5 MP
Laser Distance Meter	Yes
Wi-Fi	Yes
Video Recording	Yes
Video Output	HDMI
Minimum Focus Distance	0.15 m (0.49 ft)
Operating Temperature Range	-15°C to 50°C (5°F to 122°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
Temperature Range	0°C to +650°C
Field of View	24° × 18°
Display	4-inch LCD touchscreen
Battery Life	Approx. 4 hours
Focus	Continuous, one-shot contrast, manual
Spectral Range	7.5-14 µm
Weight	1.3 kg (2.9 lbs)
Connectivity	Wi-Fi, USB
Lens Options	14°, 24°, 42°
