FLIR T530 User Manual

Handling the camera11
Note
• Before you can enable continuous autofocus, you need to enable the laser and select
laser as focus method. See section 11.7.2 Procedure, page 34.
• When continuous autofocus is enabled, it is not possible to manually adjust the focus
by rotating the focus ring.
11.7.2 Procedure
Follow this procedure:
1. Push the navigation pad to display the menu system.
2. Select
(Settings) and push the navigation pad. This displays the Settings menu.
3. Use the navigation pad to select Device settings > Lamp & laser > Enable lamp & laser.
4. Use the navigation pad to select Device settings > Focus > Autofocus > Laser.
5. Do one of the following:
• Use the navigation pad to select Device settings > Focus > Continuous autofocus >
On.
• Touch the soft button
.
Note You can also assign the continuous autofocus function to one of the programmable
buttons
. For more information, see section 11.12 Assigning functions to the program-
mable buttons, page 37.
11.8 Operating the laser distance meter
11.8.1 General
The laser distance meter consists of a laser transmitter and a laser receiver. The laser dis-
tance meter determines the distance to a target by measuring the time it takes for a laser
pulse to reach the target and return to the laser receiver. This time is converted to a dis-
tance, which is displayed on the screen.
The laser receiver also works as a laser pointer. When the laser distance meter is on, you
will see a laser dot approximately at the target.
WARNING
Do not look directly into the laser beam. The laser beam can cause eye irritation.
#T810253; r. AA/42549/42549; en-US
34

FLIR T530 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	< 30 mK
Digital Zoom	1-4x continuous
Image Modes	Thermal, MSX, Picture-in-Picture
Storage	SD card
Image Frequency	30 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	5 MP
Laser Distance Meter	Yes
Wi-Fi	Yes
Video Recording	Yes
Video Output	HDMI
Minimum Focus Distance	0.15 m (0.49 ft)
Operating Temperature Range	-15°C to 50°C (5°F to 122°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
Temperature Range	0°C to +650°C
Field of View	24° × 18°
Display	4-inch LCD touchscreen
Battery Life	Approx. 4 hours
Focus	Continuous, one-shot contrast, manual
Spectral Range	7.5-14 µm
Weight	1.3 kg (2.9 lbs)
Connectivity	Wi-Fi, USB
Lens Options	14°, 24°, 42°
