FLIR T530 User Manual

Technical data27
27.10 FLIR T540 24°
P/N: 79302-0201
Rev.: 42542
Imaging and optical data
Infrared resolution 464 × 348 pixels
UltraMax (super-resolution) In FLIR Tools
NETD
• <30 mK, 42° @ +30°C (+86°F)
• <40 mK, 24° @ +30°C (+86°F)
• <50 mK, 14° @ +30°C (+86°F)
Field of view
• 42° × 32°
• 24° × 18°
• 14° × 10°
Minimum focus distance
• 0.15 m (0.49 ft.), 42°
• 0.15 m (0.49 ft.), 24°
• 1.0 m (3.28 ft.), 14°
• Macro mode 71 µm as option to 24°
Minimum focus distance with MSX
• 0.65 m (2.13 ft.), 42°
• 0.5 m (1.64 ft.), 24°
• 1.0 m (3.28 ft.), 14°
Focal length
• 10 mm (0.39 in.), 42°
• 17 mm (0.67 in.), 24°
• 29 mm (1.41 in.), 14°
Spatial resolution (IFOV)
• 1.66 mrad/pixel, 42°
• 0.90 mrad/pixel, 24°
• 0.52 mrad/pixel, 14°
Available extra lenses
• 42°
• 14°
Lens identification Automatic
f number
• 1.1, 42°
• 1.3, 24°
• 1.5, 14°
Image frequency 30 Hz
Focus
• Continuous LDM
• One-shot LDM
• One-shot contrast
• Manual
Field of view match Yes
Digital zoom 1–6× continuous
Detector data
Focal plane array/spectral range Uncooled microbolometer/7.5–14 µm
Detector pitch 17 µm
Image presentation
Resolution
640 × 480 pixels (VGA)
Surface brightness (cd/m
2
)
400
#T810253; r. AA/42549/42549; en-US
142

FLIR T530 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	< 30 mK
Digital Zoom	1-4x continuous
Image Modes	Thermal, MSX, Picture-in-Picture
Storage	SD card
Image Frequency	30 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	5 MP
Laser Distance Meter	Yes
Wi-Fi	Yes
Video Recording	Yes
Video Output	HDMI
Minimum Focus Distance	0.15 m (0.49 ft)
Operating Temperature Range	-15°C to 50°C (5°F to 122°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
Temperature Range	0°C to +650°C
Field of View	24° × 18°
Display	4-inch LCD touchscreen
Battery Life	Approx. 4 hours
Focus	Continuous, one-shot contrast, manual
Spectral Range	7.5-14 µm
Weight	1.3 kg (2.9 lbs)
Connectivity	Wi-Fi, USB
Lens Options	14°, 24°, 42°
