FLIR T530 User Manual

Technical data27
Video streaming
Radiometric infrared-video streaming
(compressed)
Over UVC or RTSP (Wi-Fi)
Non-radiometric video streaming (compressed: IR,
MSX, visual, Picture in Picture)
• H.264 (AVC) over RTSP (Wi-Fi)
• MPEG4 over RTSP (Wi-Fi)
• MJPEG over UVC and RTSP (Wi-Fi)
Visual video streaming Yes
Digital camera
Resolution 5 MP with LED light
Focus Fixed
Field of view
53° × 41°
Video lamp Built-in LED light
Laser pointer
Laser alignment Position is automatically displayed on the infrared
Laser distance meter Activated by dedicated button
Laser Class 2, 0.05–40 m (1.6–130 ft.) ±1% of measured
distance
Data communication interfaces
Interfaces USB 2.0, Bluetooth, Wi-Fi, DisplayPort
Bluetooth Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
Audio Microphone and speaker for voice annotation of
images
USB USB Type-C: data transfer/video/power
USB standard USB 2.0 High Speed
Video out DisplayPort
Video connector type DisplayPort over USB Type-C
Power system
Battery type Rechargeable Li-ion battery
Battery voltage 3.6 V
Battery operating time > 4 hours at 25°C (68°F) with typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or
two-bay charger
Charging time (using two-bay charger)
3.5 h to 90% capacity, on-screen indicator
External power operation
AC adapter 90–260 V AC (50/60 Hz) or 12 V from
a vehicle (cable with standard plug, optional)
Power management Automatic shut-down and sleep mode
Environmental data
Operating temperature range –15 to +50°C (5–122°F)
Storage temperature range –40 to +70°C (–40 to 158°F)
Humidity (operating and storage) IEC 60068-2-30/24 hours, 95% relative humidity,
25–40°C (77–104°F)/2 cycles
#T810253; r. AA/42549/42549; en-US
133

FLIR T530 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	< 30 mK
Digital Zoom	1-4x continuous
Image Modes	Thermal, MSX, Picture-in-Picture
Storage	SD card
Image Frequency	30 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	5 MP
Laser Distance Meter	Yes
Wi-Fi	Yes
Video Recording	Yes
Video Output	HDMI
Minimum Focus Distance	0.15 m (0.49 ft)
Operating Temperature Range	-15°C to 50°C (5°F to 122°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
Temperature Range	0°C to +650°C
Field of View	24° × 18°
Display	4-inch LCD touchscreen
Battery Life	Approx. 4 hours
Focus	Continuous, one-shot contrast, manual
Spectral Range	7.5-14 µm
Weight	1.3 kg (2.9 lbs)
Connectivity	Wi-Fi, USB
Lens Options	14°, 24°, 42°
