FLIR T530 User Manual

Technical data27
Environmental data
Operating temperature range –15 to +50°C (5–122°F)
Storage temperature range –40 to +70°C (–40 to 158°F)
Humidity (operating and storage) IEC 60068-2-30/24 hours, 95% relative humidity,
25–40°C (77–104°F)/2 cycles
EMC
• ETSI EN 301 489-1 (radio)
• ETSI EN 301 489-17
• EN 61000-6-2 (immunity)
• EN 61000-6-3 (emission)
• FCC 47 CFR Part 15 Class B (emission)
Radio spectrum
• ETSI EN 300 228
• FCC Part 15.249
• RSS-247
Encapsulation IP 54 (IEC 60529)
Shock 25g (IEC 60068-2-27)
Vibration
2g (IEC 60068-2-6)
Safety EN/UL/CSA/PSE 60950-1
Physical data
Weight (including battery) 1.3 kg (2.9 lb.)
Size (L × W × H)
• Lens vertical: 140 × 201.3 × 84.1 mm (5.5 × 7.9
× 3.3 in.)
• Lens horisontal: 140 × 201.3 × 167.3 mm (5.5 ×
7.9 × 6.6 in.)
Battery weight 195 g (6.89 oz.)
Battery size (L × W × H) 59 × 66 × 94 mm (2.3 × 2.6 × 3.7 in.)
Tripod mounting
UNC ¼″-20
Housing material
PCABS with TPE, magnesium
Color Black
Warranty and service
Warranty http://www.flir.com/warranty/
#T810253; r. AA/42549/42549; en-US
158

FLIR T530 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	< 30 mK
Digital Zoom	1-4x continuous
Image Modes	Thermal, MSX, Picture-in-Picture
Storage	SD card
Image Frequency	30 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	5 MP
Laser Distance Meter	Yes
Wi-Fi	Yes
Video Recording	Yes
Video Output	HDMI
Minimum Focus Distance	0.15 m (0.49 ft)
Operating Temperature Range	-15°C to 50°C (5°F to 122°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
Temperature Range	0°C to +650°C
Field of View	24° × 18°
Display	4-inch LCD touchscreen
Battery Life	Approx. 4 hours
Focus	Continuous, one-shot contrast, manual
Spectral Range	7.5-14 µm
Weight	1.3 kg (2.9 lbs)
Connectivity	Wi-Fi, USB
Lens Options	14°, 24°, 42°
