FLIR T530 User Manual

Terms, laws, and definitions
31
Term Definition
Qualitative thermography thermography that relies on the analysis of thermal patterns to
reveal the existence of and to locate the position of
anomalies
13
Quantitative thermography
thermography that uses temperature measurement to deter-
mine the seriousness of an anomaly, in order to establish re-
pair priorities
13
Radiative heat transfer Heat transfer by the emission and absorption of thermal
radiation
Reflected apparent temperature apparent temperature of the environment that is reflected by
the target into the IR camera
14
Spatial resolution ability of an IR camera to resolve small objects or details
Temperature measure of the average kinetic energy of the molecules and
atoms that make up the substance
Thermal energy total kinetic energy of the molecules that make up the object
15
Thermal gradient gradual change in temperature over distance
14
Thermal tuning process of putting the colors of the image on the object of
analysis, in order to maximize contrast
#T810253; r. AA/42549/42549; en-US
191
13.Based on ISO 10878-2013 (en).
14.Based on ISO 16714-3:2016 (en).
15.Thermal energy is part of the internal energy of an object.

FLIR T530 Specifications

General

Resolution	320 x 240 pixels
Thermal Sensitivity	< 30 mK
Digital Zoom	1-4x continuous
Image Modes	Thermal, MSX, Picture-in-Picture
Storage	SD card
Image Frequency	30 Hz
Accuracy	±2°C or ±2% of reading
Digital Camera	5 MP
Laser Distance Meter	Yes
Wi-Fi	Yes
Video Recording	Yes
Video Output	HDMI
Minimum Focus Distance	0.15 m (0.49 ft)
Operating Temperature Range	-15°C to 50°C (5°F to 122°F)
Storage Temperature Range	-40°C to 70°C (-40°F to 158°F)
Temperature Range	0°C to +650°C
Field of View	24° × 18°
Display	4-inch LCD touchscreen
Battery Life	Approx. 4 hours
Focus	Continuous, one-shot contrast, manual
Spectral Range	7.5-14 µm
Weight	1.3 kg (2.9 lbs)
Connectivity	Wi-Fi, USB
Lens Options	14°, 24°, 42°
