The table below shows the components of the FGM 130 that can be re-used when upgrading
to the FGM 160.
FGM 130
FGM 160
Flow Computer
No
Replaced by FGM 160 Computer
Field Electronics Enclosure
No
Integrated in FGM 160 Computer
Ultrasonic Sensors
No
New FGM 160 sensors
Pressure Transmitter
Yes
Interface directly to FGM 160 Computer
Temperature Transmitter
Yes
Interface directly to FGM 160 Computer
Power Cable
Yes
Power or Communication
Fiber Optic Signal Cable
Yes
Communication (RS422/RS485)
Sensor Holders
Yes
DCS/SCADA Interface
Yes
Compatible, with an additional HART
interface
7. REFERENCES
[1] FGM 160 – Preservation, Packing, Unpacking and Storage Procedure
[2] FGM 160 – Hazardous Area Installation Guidelines
[3] FGM 160 – Field Wiring Diagram, Fluenta Doc.no.: 77.120.509
[4] FGM 160 – DCS Modbus Interface Specifications
[5] FGM 160 – Operator Console Description
[6] FGM 160 – HART Output Interface Specification
