Fluidwell F115-P User Manual

FW_F115-P_M_v2201-01_EN.docx
Page 12
3.2.4 RETURNING TO OPERATOR-LEVEL
When all settings are configured correctly, the unit can be returned to OPERATE-level.
Please keep a record of all settings for later reference.
Use the control panel to return to OPERATE-level
PROG-key
In order to return to the operator level, press the PROG-key for three seconds.
When no keys are pressed for 2 minutes, SETUP-level will be left automatically.
3.3 CONFIGURATION SETTINGS
All settings of the F115-P can be set via the control panel.
The following paragraphs give a detailed description of each setting.
3.3.1 SETUP MENU - SETTINGS
SETUP FUNCTIONS AND VARIABLES
1
TOTAL - A
1.1
UNIT
L; m
3
; kg; lb; GAL; USGAL; bbl; no unit
1.2
DECIMALS
0000000; 111111.1; 22222.22; 3333.333
1.3
K-FACTOR
0.000010 - 9999999
1.4
DECIMALS K-FACTOR
0 - 6
2
FLOW RATE - A
2.1
UNIT
mL; L; m
3
; mg; g; kg; ton; gal; bbl; lb; cf; rev; - - - - (no unit); scf; nm
3
; nL; p
2.2
TIME
/sec; /min; /hour; /day
2.3
DECIMALS
0000000; 111111.1; 22222.22; 3333.333
2.4
K-FACTOR
0.000010 - 9,999,999
2.5
DECIMALS K-FACTOR
0 - 6
2.6
CALCULATION
per 1 - 255 pulses
2.7
CUT-OFF
0.1 - 999.9 seconds
3
TOTAL - B
3.1
K-FACTOR
0.000010 - 9999999
3.2
DECIMALS K-FACTOR
0 - 6
4
FLOW RATE - B
4.1
K-FACTOR
0.000010 - 9,999,999
4.2
DECIMALS K-FACTOR
0 - 6
5
DISPLAY
5.1
FUNCTION
total; rate; all
5.2
SHOW A-B
enable, disable
5.3
LIGHT
0% (off); 20%; 40%; 60%; 80%; 100% (full brightness)
6
POWER MANAGEMENT
6.1
LCD NEW
fast; 1 sec; 3 sec; 15 sec; 30 sec; off
6.2
BATTERY MODE
operational; shelf
7
FLOWMETER
7.1
SIGNAL A
npn; npn-lp; reed; reed-lp; pnp; pnp-lp; namur; coil-hi; coil-lo; 8-1 DC; 12 DC; 24 DC
7.2
SIGNAL B
npn; npn-lp; reed; reed-lp; pnp; pnp-lp; namur; coil-hi; coil-lo; 8-1 DC; 12 DC; 24 DC
7.3
BI-DIRECTIONAL
disable, enable
7.4
PHASE
90 deg, 270 deg
7.5
COUNT NEGATIVE
disable, enable
7.6
K-FACTOR
single, dual
7.7
CALCULATE
add, differ
8
ANALOG
8.1
OUTPUT
disable; enable
8.2
RATE-MIN
000.000 - 999999
8.3
RATE-MAX
000.000 - 999999
8.4
RATE-SEL
signed, absolute, rate-A, rate-B
8.5
CUT-OFF
0.0 - 9.9%
8.6
TUNE-MIN
0 - 9999
8.7
TUNE-MAX
0 - 9999
8.8
FILTER
01 - 99
