Fluidwell F115-P User Manual

FW_F115-P_M_v2201-01_EN.docx
Page 50
APPENDIX A TECHNICAL SPECIFICATION
General
Display
Type
High intensity numeric and alphanumeric LCD, UV-resistant.
Digits
Seven 17mm (0.67") and eleven 8mm (0.31"). Various symbols and measuring units.
Refresh rate
User definable: 8 times/sec - 30 secs.
Type ZB
LCD with LED backlight. Improved readability in full sunlight and darkness.
Power requirements: Supplied from type PX, PD, PF or PM.
Not available intrinsically safe.
Enclosures
General
Control Keys
Coating
Die-cast aluminum or GRP (Glass fiber Reinforced Polyamide) enclosure with polycarbonate
window, silicone and EPDM gaskets. UV stabilized and flame retardant material.
Three industrial micro-switch keys. UV-resistant silicone keypad.
Aluminum enclosure only: UV-resistant 2-component industrial coating.
Panel mount enclosures
Dimensions
Panel cut-out
Protruding at front
Classification
Weight (approx.)
130 x 120 x 60mm (5.10” x 4.72” x 2.38”) – WxHxD
115 x 98mm (4.53" x 3.86") – WxH
31mm (1.22")
IP65 / TYPE 4X
GRP 450 gr. / 1.0 lbs
Aluminum 0.6 kg / 1.3 lbs
Stainless steel 1 kg / 2.2 lbs
Field/wall-mount enclosures
Dimensions
with extended back
Classification
Weight (approx.)
130 x 120 x 75mm (5.10” x 4.72” x 2.95”) – WxHxD
130 x 120 x 90mm (5.10” x 4.72” x 3.54”) – WxHxD
IP67 / TYPE 4X
GRP 0.6 kg / 1.3 lbs
Aluminum 1 kg / 2.2 lbs
Stainless steel 1.5 kg / 3.3 lbs
Aluminum / SS enclosures
Type HA
Type HB / HSB
Type HL
Type HM / HBM / HSM
Type HN
Type HO / HBO / HSO
Type HP
Type HT
Type HU / HBU / HSU
Type HV
Type HZ
GRP enclosures
Type HC
Type HD
Type HE
Type HF
Type HG
Type HH
Type HJ
Type HK
(types HS_ are stainless steel versions, HB_ are extended aluminum back versions)
Drilling: 2x PG9 – 1x M20
Panel mount front cover only
Drilling: 2x ½”NPT
Drilling: 2x M16 – 1x M20
Drilling: 1x M20
Drilling: 2x M20
Drilling: 6x M12
Drilling: 1x ½”NPT
Drilling: 3x ½”NPT
Drilling: 4x M20
No drilling.
Panel mount front cover only
No drilling
Drilling: 2x 16mm (0.63”) – 1x 20mm (0.78”)
Drilling: 1x 22mm (0.87”)
Drilling: 2x 20mm (0.78”)
Drilling: 6x 12mm (0.47”)
Drilling: 3x 22mm (0.87”)
Flat bottom - no drilling.
Operating temperature
Operational
-40°C to +80°C (-40°F to +176°F)
Intrinsically safe
-40°C to +70°C (-40°F to +158°F). For EPL Da: -40°C to +50°C (-40°F to +122°F)
Relative humidity
90%, no condensation allowed.
