Fluidwell F115-P User Manual

FW_F115-P_M_v2201-01_EN.docx
Page 51
Power supply
Type AP
Loop-powered from 4-20mA output signal - 8-30V DC. Power consumption max. 0.5 Watt.
Type PB
Standard lithium battery - life-time depends upon settings - up to 5 years. SAFE AREA ONLY
Type PC
Intrinsically Safe lithium battery - life-time depends upon settings - up to 5 years.
Type PD
8-24V AC / 8-30V DC; Power consumption max. 5 Watt.
Type PD-ZB
10-24V AC / 12-30V DC; Power consumption max. 5 Watt.
Type PD-XI
16-30V DC; Power consumption max. 1 Watt.
Type PF
15-24V AC / 20-30V DC; Power consumption max. 15 Watt.
Type PM
115-230V AC; Power consumption max. 15 Watt.
Type PX
8-30V DC; Power consumption max. 0.75 Watt.
Type PX-ZB
12-30V DC; Power consumption max. 1.5 Watt.
Type PX-XI
8-30V DC; Power consumption max. 0.75 Watt.
Note I.S. applications
For Intrinsically safe applications, consult the safety values in Annex 1 of the certificate.
Sensor supply
Selection
(see 4.5.5 or 5.2.5 for I.S.)
Internal sensor supply
External sensor supply
3 V (low power signal), 1.2 VDC (coil pick-up)
8.2 V
12 V
24 V
Type PB / PC / AP
Max 0.1 mA
Not available
Type PD
Max. 1 mA
Max. 20 mA
Max. 20 mA
Max. 50 mA
Type PD-XI
Max. 7 mA
Not available
Type PF
Max. 50 mA
Max. 50 mA
Max. 50 mA
Type PM
Max. 50 mA
Max. 50 mA
Max. 400 mA
Type PX
Not available
Type PX-XI
See section 5.2.4 and 5.2.5
Note I.S. applications
For Intrinsically safe applications, consult the safety values in Annex 1 of the certificate.
Terminal connections
Type:
Removable plug-in terminal strip. Wire max. 1.5 mm
2
and 2.5 mm
2
Data protection
Type
EEPROM backup of all setting. Backup of running totals every minute.
Data retention at least 10 years.
Password
Configuration settings can be password protected.
Hazardous area (option)
Intrinsically safe
Type XI
ATEX approval: KEMA 03ATEX1074 X
II 1 G Ex ia IIB/IIC T4 Ga
II 1 D Ex ia IIIC T
200
100°C Da
IECEx approval: IECEx DEK 11.0042X
Ex ia IIB/IIC T4 Ga
Ex ia IIIC T
200
100°C Da
Explosion proof
Type XF
ATEX approval:
II 2 G Ex d IIB T5 Gb
II 2 D Ex t IIIB T100 °C Db
IECEx approval:
Ex d IIB T5 Gb
Ex t IIIB T100 °C Db
Weight
Dimensions
Appr. 15 kg.
350 x 250 x 200mm (13.7” x 9.9” x 7.9”) WxHxD.
Directives & Standards
EMC
EN 61326-1 FCC 47 CFR part 15
Low voltage
EN/IEC 61010-1 CSA C22.2 No. 61010-1 UL61010-1
ATEX
EN IEC 60079-0 EN 60079-11
IECEx
IEC 60079-0 IEC 60079-11
RoHS
EN 50581 IEC 63000
IP & NEMA
EN 60529 ANSI/IEC 60529 NEMA 250
Note
See the applicable Declaration of Conformity or product certificate for specific revisions and
publication dates.
