Fluidwell F115-P User Manual

FW_F115-P_M_v2201-01_EN.docx
Page 62
LIST OF CONFIGURATION SETTINGS
SETTING
DEFAULT
DATE :
DATE :
1  TOTAL - A
Enter your settings here
1.1 unit
L
1.2 decimals
0000000
1.3 K-Factor
0000001
1.4 decimals K-Factor
0
2 - FLOW RATE - A
2.1 unit
L
2.2 time
/min
2.3 decimals
0000000
2.4 K-Factor
0000001
2.5 decimals K-Factor
0
2.6 calculation
010
2.7 cut-off
30.0 sec.
3  TOTAL - B
3.1 K-factor
= setting 1.3
3.2 decimals K-factor
= setting 1.4
4  FLOW RATE - B
4.1 K-factor
= setting 2.4
4.2 decimals K-factor
= setting 2.5
5 - DISPLAY
5.1 function
total
5.2 show A-B
enable
5.3 light
100%
6 - POWERMANAGEMENT
6.1 LCD-new
1 sec.
6.2 mode
operate
7 - FLOWMETER
7.1 signal A
coil lo
7.2 signal B
coil lo
7.3 bi-directional
disable
7.4 phase
90 deg
7.5 count negative
enable
7.6 K-factor
single
7.7 calculate
differ
8 - ANALOG OUTPUT
8.1 output
disable
8.2 rate-min
0000000
8.3 rate-max
9999999
8.4 rate-neg
ignore
6.4 cut-off
0.0%
6.5 tune-min
factory set
6.6 tune-max
factory set
6.7 filter
0 (off)
9 - PULSE
9.1 mode
signed
9.2 width
0.000
9.3 decimals
0
9.4 amount
0001000
