Fluke 190-104 - Input C AC Voltage Accuracy (HF) & Bandwidth Test

Performance Verification
4.6 Scope Input A, B, C, D Tests 4
4-25
190-104 10 ns/div 400 mV pp 100 MHz 1 div
10 ns/div 800 mV pp 150 MHz 2 div
190-204 10 ns/div 400 mV pp 200 MHz 1 div
10 ns/div 800 mV pp 250 MHz 2 div
4.6.14 Input C AC Voltage Accuracy (HF) & Bandwidth Test
Proceed as follows to test the Input C high frequency automatic scope ac voltage
measurement accuracy, and the bandwidth:
1. Connect the Test Tool to the 5500A as for the previous test (see Figure 4-9).
2. Select the following Test Tool setup:
• Recall the created setup (e.g. SETUP 1, see section 4.4.3): press
SAVE
,
F2
RECALL , select SCREEN+SETUP 1 , press
ENTER
to recall the setup .
• Press
SCOPE
, then press
F3
READING 2 , and select on C | V ac.
• Press
MANUAL
AUTO
to select autoranging (AUTO in upper right LCD edge)
• Using
mV
RANGE
and
V
RANGE
change the sensitivity range to select manual sensitivity
ranging, and lock the Input C sensitivity range on 500 mV/div.
3. Set the 5500A to source a sine wave, to the first test point in Table 4-13.
4. Observe the Input C reading and check to see if it is within the range shown under
the appropriate column of table 4-13.
5. Continue through the test points.
6. When you are finished, set the 5500A to Standby.
Table 4-13. HF AC Voltage Verification Points
UUT 5500A SC... MODE levsin UUT
Model Voltage Frequency Reading C
all 2.545 Vpp 1 MHz 835 mV to 965 mV
all 2.545 Vpp 25 MHz 790 mV to 1.010 V
190-104 2.545 Vpp 100 MHz >630 mV
190-204 2.545 Vpp 200 MHz >630 mV
