4.4.3 Creating Test Tool Setup1
Before starting the verification procedure you must define a standard Test Tool setup,
called SETUP 1. During verification you will be asked to recall this setup. This defines
the initial Test Tool setup for each verification.
Proceed as follows to create a setup (for instance SETUP1):
1. Reset the Test Tool. Input A is ON, other inputs are OFF now.
2. Press
B
. The black text with yellow background indicates the actual settings.
3. Press
F1
(toggle key) to select INPUT B ON. The Input B trace will become
visible.
4. Press
F3
to change the PROBE B setting.
5. Select
Probe Type: Voltage | Attenuation: 1:1 .
6. Press
C
and press
F1
(toggle key) to select INPUT C ON.
7. Press
F3
to change the PROBE C setting.
8. Select
Probe Type: Voltage | Attenuation: 1:1 .
9. Press
D
and press
F1
(toggle key) to select INPUT D ON.
10. Press
F3
to change the PROBE D setting.
11. Select
Probe Type: Voltage | Attenuation: 1:1 .
12. Press
A
. The inverse text indicates the actual settings.
13. Press
F3
to change the PROBE A setting.
14. Select
Probe Type: Voltage | Attenuation: 1:1 .
15. Press
SCOPE
.
16. Press
F1
– READINGS ON.
17. Press
F2
– READING ... and select with
F1
– READINGS and with the
arrow keys:
Reading 1, on A, V dc,
Reading 2, on B, V dc,
Reading 3, on C, V dc,
Reading 4, on D, V dc.
18. Press
F4
CLOSE .
19. Press
F4
WAVEFORM OPTIONS and select
Glitch: Off | Acquisition: Normal | Average: Off | Waveform: NORMAL .
20. Press
MANUAL
AUTO
to select MANUAL ranging (MANUAL in upper left of screen) .
21. Press
SAVE
.
22. Press
F1
SAVE...
