Fluke 190-104 - Input ABCD Position; Input ABCD Volt Gain

Calibration Adjustment
5.6 Final Calibration 5
5-15
Table 5-5. Input ABCD Gain Calibration Points
Cal step UUT input value (5500A SCOPE, MODE volt, SCOPE Z 1 MΩ, 1 kHz)
CL 0660 300 mV
CL 0604 500 mV
CL 0637 none (5500 standby)
CL 0504 500 mV
CL 0624 none (5500 standby)
CL 0599 10 mV
CL 0600 25 mV
CL 0601 50 mV
CL 0602 100 mV
CL 0603 250 mV
CL0662 2 V
CL 0605 1 V
CL 0606 2.5 V
CL 0607 5 V
CL0664 20 V
CL 0608 10 V
CL 0609 25 V
CL 0610 50 V (set 5500A to OPR!)
5.6.7 Input ABCD Position
Proceed as follows to do the Input ABCD Position calibration:
1. Press
F2
to select calibration adjustment step CL 0619.
2. Remove all Input A, B, C, D connections (open inputs).
3. Press
F3
to start the calibration
4. Wait until the display shows calibration status
:READY.
5. Continue at Section 5.6.8
5.6.8 Input ABCD Volt Gain
Warning
Dangerous voltages will be present on the calibration source
and connection cables during the following steps. Ensure that
the calibrator is in standby mode before making any connection
between the calibrator and the Test Tool.
