Fluke 190-104/190-204
Service Information
5-18
Calibration data valid.
Save data and exit maintenance mode?
Note
Calibration data valid indicates that the calibration adjustment procedure
is performed correctly. It does not necessarily mean that the Test Tool
meets the characteristics listed in Chapter 2.
3. Press
F4
YES to save and exit.
Note 1
After saving the calibration data, the calibration number and - date will be
updated if the calibration data have been changed and the data are valid.
The calibration number and - date will not change if:
- the calibration mode is entered and left without doing a calibration adjustment.
- only the contrast calibration adjustment (5.4) and/or the probe calibration is
done.
Note 2
If you press
F3
NO ,the Test Tool returns to the calibration mode. You can
either calibrate the Test Tool again, or press
F4
EXIT ,
F4
YES to
save and exit.
Possible error messages.
The following messages can be shown on the Test Tool display:
WARNING: Calibration data not valid.
Save data and exit maintenance mode?
Proceed as follows:
• If you did the WarmingUp and Pre-Calibration successfully (section 5.5), and you
want to store the Pre-Calibration data before continuing with the Final Calibration:
⇒ Press
F4
YES.
When turning the Test Tool off and on again, it will show the message:
The instrument needs calibration.
Please contact your service center.
The calibration date and number will not be updated. You must continue with the Final
Calibration!
• To return to the Maintenance mode, if you want to repeat the complete calibration:
⇒ Press
F3
NO.
Now press
F1
until the display shows WarmingUp (CL 0200):IDLE, and
calibrate the Test Tool, starting at section 5.5.
• If you want to exit and maintain the old calibration data:
⇒ Turn the Test Tool off.
