Fluke 716 User Manual

Process Calibrators
Replacement Parts and Accessories
73
Replacement Parts and Accessories
Table 71 lists the replaceable parts and accessories for the 71X Calibrators. See Figure 7
for an exploded view of the 718 Calibrator. Fluke repair is recommended for the 718Ex
and no 718Ex replacement parts are listed in Table 71.
Note
Not all parts listed in Table 71 are shown in Figure 7.
Table 71. Replaceable Parts and Accessories
Ref.
Des.
Description
PN or
Model No.
Used On Qty.
A1 Assembly 690906
691147
718 30G
718 100G
1
BT1, BT2 9V battery, ANSI/NEDA 1604A or IEC 6LR61 614487 71X 1
WF1 Fuse, 125 mA, 250V fast 686527 71X 1
WF2 Fuse, 125 mA, 250V fast 686527 715 1
H2,3,4 Case screw 832246 71X 3
H5,6 Battery door fasteners 948609 71X 2
H7,8 Bracket screw 641131 718 2
MP1 LCD Bezel 620242
620259
620267
620275
646866
664000
2545064
663997
1638728
2545073
2545099
2545105
2545110
2545122
2545131
2545047
664158
664169
2545058
712
713 30G
713 100G
714
714
716
717 1G
717 30G
717 100G
717 300G
717 500G
717 1000G
717 1500G
717 3000G
717 5000G
718 1G
718 30G
718 100G
718 300G
1
MP2 LCD 686490
686482
712,714,715
713,716,717,
718
1
MP6 1G Pump 2571725 718 1
MP6 30G, 100G, 300G Pump Assembly 2558508 718 1
MP7,8 Selector knob 664193 718 2
MP9 Vernier adjust knob 664190 718 1
MP10 Pump handle knob 664185 718 1
MP11,12,13 O-ring, for pressure input 146688 713,717,718 1
MP14 Spacer for pressure input 687449 713,717,718 1
MP20 Shield, LCD, Top Case 687092 71X 1
MP21 LCD Zebra Strip 643376 71X 2
MP22 O-ring for input/output receptacle 831933 712,715 1
