Fluke 716 User Manual

71X Series
Calibration Manual
12
Table 13. 713 Pressure Range and Resolution
Displayed
Pressure Units
Model 713 30G
Range and Resolution
Model 713 100G
Range and Resolution
psi 30.000 psi 100.00 psi
inH
2
O at 4 °C 830.4 inH
2
O 2768.0 inH
2
O
inH
2
O at 20 °C 831.9 inH
2
O 2772.9 inH
2
O
cmH
2
O at 4 °C, 2109.0 cmH
2
O 7030 cmH
2
O
cmH
2
O at 20 °C 2113.0 cmH
2
O 7043 cmH
2
O
bar 2.0685 bar 6.895 bar
mbar 2068.5 mbar 6895 mbar
kPa 206.85 kPa 689.5 kPa
inHg 61.080 inHg 203.6 inHg
mmHg 1551.3 mmHg 5171 mmHg
kg/cm
2
2.1090 kg/cm
2
7.030 kg/cm
2
Table 14. 713 30G and 713 100G DC mA Input
Range Resolution
Accuracy,
±(% of Reading + Counts)
24 mA 0.001 mA 0.025 + 1
Overload protection: 125 mA, 250 V fast acting fuse
Temperature coefficient: 0.005 % of range per °C for temperature ranges – 10 °C to 18 °C and 28 °C to
55 °C
714 Specifications
714 Calibrator specifications vary based on the version of the instrument. To display the
firmware version for your instrument, start with the 714 off, press and hold {, then
press the power button. Find the section heading below for the displayed version and use
the specification tables in that section to test and calibrate the instrument.
Firmware Earlier than v2.0
Table 15. 714 Temperature Measure and Thermocouple Simulate
TC Type Resolution Error Reference Junction Error
J, K, T, E, L, U 0.1 °C ± (0.3 °C + 10 µV) ± 0.2 °C
B, R, S 1 °C ± (0.3 °C + 10 µV) ± 0.2 °C
Maximum input voltage: 30 V
Temperature Coefficient: 0.05 x specified accuracy per °C for temperature ranges – 10 °C to 18 °C and
28 °C to 55 °C
