Calibration Bath
Controller Operation
31
Set-points
The next parameters are the program set-points. For example:
1 50.0 First set-point
1. Use the UP or DOWN buttons to select any of the set-points. For example, set-point 3:
3 30.0 Third set-point
2. Push SET to be able to change the set-point.
3. Use UP or DOWN to change the set-point value.
4. Push SET to save the new set-point value.
Set the other set-points in the same manner. Once you program the set-points, push EXIT to
continue to the next function.
Program Soak Time
The next menu parameter is soak time. Soak time is defined as the minutes that each program
set-point is maintained after settling before proceeding to the next set-point. At the point the
temperature reaches its set-point, the duration is counted. For example:
Pt=15 Soak time in minutes
1. Push UP or DOWN to change the time.
2. Push SET to continue.
Program Function Mode
The next parameter in the menu is the program function or cycle mode. There are four possible
modes that determine whether the program scans up only (from set-point 1 to n) or both up and
down (from set-point n to 1), also whether the program stops after one cycle or repeats the cycle
indefinitely. Ta ble 3 below shows the action of each of the four program mode settings.
To select the program mode (
PF):
PF=1 Program mode
1. Use the UP or DOWN buttons to change the mode.
2.
PF=4 New program mode
3. Push SET to continue.
Table 3. Program Setting Mode Actions
Function Action
1up-stop
2 up-down-stop
3 up-repeat
4 up-down-repeat
